Mindray PM-60 Pulse Oxymeter
zoom_out_map

Mindray PM-60 Pulse Oxymeter

N-OXY35060
New product
€390.00
Available

Mindray PM-60 Pulse Oxymeter

PM-60 is a miniature, lightweight device capable of spot-check and continuous monitoring of SpO2 and pulse rate.

Supplied with adult reusable sensor.

- suitable for adult and pediatric patients

- high resolution 2.4" colour LCD display

- adjustable visual and audible alarms

- real-time data transfer by infrared technology

WhatsApp Chat



Worldwide Delivery



After Sales Service Guaranteed



Secured Payment

Mindray PM-60 Pulse Oxymeter

PM-60 is a miniature, lightweight device capable of spot-check and continuous monitoring of SpO2 and pulse rate.

Supplied with adult reusable sensor.

Spot Check Mode :

- auto-standby and power off during the idle status

- auto-increase the patients IDs

- non-alarm setting for “sensor off“ occasion 1-99 IDs for maximum 4,000 sets of measurements

Continuous monitoring mode :

- regular alarm handing

- enable to input patient ID manually

- view SpO2 waveform for maximum 96 hours trend

Other features :

- suitable for adult and pediatric patients

- high resolution 2.4" colour LCD display

- adjustable visual and audible alarms

- real-time data transfer by infrared technology

- choose between Lithium-ion or AA alkaline batteries (for up to 36 hours continuous working) depending on your run-time needs

- protective cover perfect for portable monitoring needs (optionale)

Size: 55 x 120 x 30 mm

Weight: 300 g with battery

N-OXY35060

Specific References

New product

• Display: 2.4“ color TFT Resolution: 320 x 240

• Multi dispays selectable: standard or waveform screen

• Trace: 1 plethysmogram waveform

• Indicator: alarm indicator light, power indicator light, pulse tone, alarm sound, button tones

• Interface: dual-purpose socket for connecting SpO2 sensor and communication cable IR interface: infrared link allows downloading realtime patient data to computer

• DC power interface: Charger stand for Li-ion battery

• DC power requirements: input voltage 5V DC Power 1.2A

• Battery:

- Li-ion battery 24 hours continuous working

- 3xAA batteries 36 hours continuous working

• Trend memory:

- Monitoring mode: Resolution: 2s - Maximum time: 96 h

- Spot-check mode: Review of up to 4000 data, measure up to 99 patients

• Alarm: user adjustable high and low limits 3-level audible and visual alarm

SpO2

• Measurement range: 0~100% ±2% (70~100%)

• Resolution: 1% Alarm range: 50~100%

• Refreshing rate: 1 s

• Averaging time:

- 7 s (sensitivity set HIGH)

- 9 s (sensitivity set MED)

- 11 s (sensitivity set LOW)

Pulse rate

• Range: 18~300 bpm (±3 bpm non-motion)

(±5 bpm motion)

Alarm range: 18~300 bpm

• Resolution: 1 bpm

• Refreshing rate: 1 s

• Averaging time: same as SpO2

• Type of protection: Class II with internal electric power supply

• Degree of protection: BF (defibrillation proof)

• Protection against ingress of liquid: IPX 2
