AGFA Drystar 5302 Dry Laser Imager
05012202
Second Hand
AGFA Drystar 5302 Dry Laser Image
High quality images anywhere and everywhere
Premium print quality in a convenient tabletop format for application-specific images.
With low capital and operating costs, this makes the DRYSTAR 5302 the ideal solution for your printing needs.
Worldwide Delivery
After Sales Service Guaranteed
Secured Payment
AGFA Drystar 5302 Dry Laser Imager
High quality images anywhere and everywhere
Premium print quality in a convenient tabletop format for application-specific images.
With low capital and operating costs, this makes the DRYSTAR 5302 the ideal solution for your printing needs.
Its rugged design provides long-lasting, reliable operation, while its two in-line feeders and small footprint ensure maximum flexibility.
You can place it wherever you want and it adapts to your imaging needs, providing an affordable and reliable answer to your digital radiology and X-ray printing. Plus, you get the added benefits of the DRYSTAR family, including Direct Digital Imaging (DDI) technology, further enhanced by Agfa's A#Sharp; easy, green operation and maintenance; and simple, native DICOM integration.
The DRYSTAR 5302 is the flexible solution for your daily activities.
05012202
Specific References
Second Hand
Dimensions & weight:
- Dimensions (W x D x H): 72.8 x 71.5 x 53.6 cm (H = 67.6 cm including receiving tray)
- Weight (without film): 90 kg
Power supply:
- 100 - 240 V automatic adaptation: 50/60 Hz
Power consumption:
- Printing: 250 watts
- Maximum power consumption: 530 watts
- Sleep Mode: 70 watts
Feed Tray Capacity:
- 100 sheets per input tray
Environmental conditions:
- Temperature: 15 - 30 °C
- Humidity: 20 - 75% relative humidity, non-condensing
Storage/Transportation Conditions
- Temperature: -25 to +55 °C -40 to +70 °C for transport
- Humidity: 10 - 95% relative humidity, non-condensing
Safety:
- IEC 60601-1
- UL 60601-1
- CSA 22.2 no. 601.1-M90
- VDE 0750
- CCC GB4943 (China)
- Safety labels UL, cUL, TÜV-Mark, CCC-Mark PERFORMANCE
Throughput:
- 8 x 10 inch: 140 films/hour (26 sec. per film) / 20.32 x 25.4 cm
- 11 x 14 inch: 86 films/hour (42 sec. per film) / 27.94 x 35.56 cm
- 14 x 17 inch: 75 films/hour (48 s. per film) / 35.56 x 43.18 cm
- Access time to the first sheet: 77 s. (14 x 17 inch - 12-bit)
Diagnostic area:
- 8 x 10 inch: 2376 x 3070 pixels / 20.32 x 25.4 cm
- 10 x 12 inch: 3070 x 3653 pixels / 25.4 x 30.48 cm
- 11 x 14 inch: 3348 x 4358 pixels / 27.94 x 35.56 cm
- 14 x 17 inch: 4358 x 5232 pixels / 35.56 x 43.18 cm
Print resolution:
- Geometric: 320 ppi
-Contrast: 12 bit contrast resolution FILMS Types
