Maxtec OM25-ME Oxygen Monitor

Reference 03062205

Condition Second Hand

€200.00 Tax excluded

Available

The OM-25ME is for use anywhere high/low limit alarms are deemed important. It is great for use in-line with older ventilators, or delivering O2 in conjunction with a blender or heart lung machine.

WhatsApp Chat

Worldwide Delivery

After Sales Service Guaranteed

Secured Payment

The OM-25ME is designed primarily for continuous monitoring of oxygen levels delivered by medical oxygen delivery equipment and respiratory care systems. Adjustable high and low level alarm setpoints make the OM-25ME ideal for use in neo-natal, anesthesia, and respiratory care.

The MAXO2 (Model OM-25ME) provides unparalleled performance and reliability, due to an advanced design that includes the following features and operational benefits.

• Fast-responding, oxygen-specific, galvanic sensor that achieves 90% of final value in approximately 15 seconds at room temperature.

• Extra-life oxygen sensor of approximately 900,000 O2 percent hours (minimum 2 years in most applications).

• External probe with 10 ft., extendible cable and diverter fitting for standard 15 mm "T" adapter.

• Operation using 2 AA alkaline batteries (2 x 1.5 volts) for approximately 3000 hours of performance in typical usage (not in alarm conditions). For extra extended long life, 2 AA lithium batteries may be used.

• Durable, compact case that weighs less than 1 pound and permits comfortable, hand-held operation.

• Large, easy-to-read, 3 1/2-digit LCD display for readings in the 0-100% range.

• Adjustable high-level and low-level alarming capability with flashing LED and audible indication of alarm conditions.

• Simple operation and calibration using quick-calibrate key functions.

• Self-diagnostic check of analog and microprocessor circuitry.

• Low battery indication.

Reference 03062205

Specific References

Condition Second Hand

Range: 0-100%
Response time: 90% of final value < 15 seconds at 23o C.
Warm-up Time: none required
Cable length: 10 ft. fully extended
Probe deflector fitting: to fit 15 mm (I.D.) “T” adapter
Weight: 0.70 lbs. (317g)
Min./Max. Storage Temp: -15°C - 50°C (5°F - 122°F)
Operating Temperature: 59°F - 104°F (15°C - 40°C)
Dimensions: 3.5”(W) x 5.5”(H) x 1.5”(D) [89mm x 140mm x 38mm]
Power Requirements: 2, AA Alkaline batteries (2 x 1.5 Volts)
Sensor Type: Maxtec® MAX-250E galvanic fuel cell
High alarm (monitor only): 18-99%
Low alarm range (monitor only): 15-99%
Alarm Accuracy: Exact to displayed O2 values
Alarm System (monitor only): flashing red LED, audible tone of 2300 Hz nominal
Linearity: ± 1% of full scale at constant temperature and pressure.
Accuracy: ± 1% of full scale at constant temperature, RH and pressure / ± 3% actual oxygen level over full operating temperature range.
