Contec 3 Channels ECG - control of up to 12 leads

12-lead Electrocardiogram with thermal printer and built-in database. It measures, analyzes and interprets data automatically.



Worldwide Delivery



After Sales Service Guaranteed



Secured Payment

Contec 3 Channels ECG - control of up to 12 leads

Features:

  • 3.5" TFT colour LCD screen
  • 12 leads simultaneous display
  • Thermal printing system
  • AC and DC power supply
  • High capacity built-in lithium rechargeable battery
  • Battery power supports up to 150 ECG continuous records
  • Built-in Database
  • Built-in memory can store more than 1000 cases
  • Digital signal processor for filter
  • Auto-measurement, auto-analysis, auto-interpretations
  • ECG-Sync software, USB connection to PC
  •  Internal software: GB, FR, IT, ES, DE, TR, PL, PT, RU, KZ
  •  PC software: GB

USB connection allows real-time transmission to PC, remote data analysis and diagnosis, management and printing through the PC.

Standard Accessories:

  • ECG cable - 1 set
  • Limb electrode clamp - 1 set
  • Chest electrodes - 1 set
  • Ground wire
  • Power connection
  • Paper roll
  • USB connection and PC software
N-33221

Specific References

New product

ECG Instrument Input

  • Safety Type: Class I, type CF applied part, which has defibrillation-proof applied part
  • Lead Standard 12 leads
  • Input way: Floating and defibrillation protection
  • Patient leak current: <10µA
  • Sampling rate: 1000Hz
  • A/D conversion: 12bit
  • Frequency response 0.05Hz~150Hz (-3dB, + 0.4dB)
  • Time constant: >3.2s
  • CMRR: >60dB, >100dB(Add filter)
  • Enduring polarization: voltage ±500mV
  • Noise level: <15µVp-p

Dispose Wave Data

  • EMG interference filter: 25Hz/35Hz (-3dB)
  • AC filter 50Hz/60Hz (=20dB)

Waveform Output

  • Recording way: Thermal printing system (32spots/mm)
  • Recording paper: 80mm(W)×20m(L)
  • Sensitivity: 2.5, 5, 10, 20, 40 mm/mV
  • Paper speed:
    - Auto-record: auto leads changing
    - Rhythm record: 25 mm/s, 50 mm/s
    - Manual-record: 5, 6.25, 10, 12.5, 25, 50 mm/mV

Power Supply

  • AC: 110-220V, 50/60 Hz
  • DC: 7.4V, 3500 mAh rechargeable lithium polymer battery

Fuse

  • 2 pcs f5×20mm AC time lag; T250mA/250V(Power Supply:220V)

Form

  • Size 315 x 215 x 77 mm
  • Net Weight 1.6 kg
